7.2 Ch. 80W 8K AV Receiver with HEOS® Built-in
Designed for 4K or 8K setups, the AVR-X1700H delivers the ultimate 3D audio home theater/gaming experiences and supports the latest HDMI specifications.
-
Powerful, discrete 7-channel amplifier
Delivers maximum performance and 80W per channel to provide the classic and dynamic Denon sound experience.
-
Advanced 8K HDMI video with eARC support
Three 8K inputs support the latest HDMI specifications—8K/60Hz, select 4K/120Hz pass-through, VRR, Dolby Vision™, HDR10+, ALLM.
-
Full 3D audio support with virtual surround sound
Enjoy immersive 3D audio with Dolby Atmos®, Dolby Atmos Height Virtualization Technology, DTS:X®, and DTS Virtual:X™.
-
Enhanced gaming experiences
Variable Refresh Rate (VRR) and Auto Low Latency Mode (ALLM) care for amazing imaging as well as reduced lag and latency.
TECHNICAL SPECIFICATIONS
Multichannel Surround
|
DTS HD Master / DTS:X |
Yes / Yes |
| DTS Neo:X / DTS Neural:X | No / Yes |
| DTS Virtual:X | Yes |
| Dolby TrueHD / Dolby Atmos | Yes / Yes |
| Dolby ProLogic II / Dolby Surround | No / Yes |
| Dolby Height Virtualization | Yes |
| Multichannel Stereo | Yes |
| Dialog Enhancer | Yes |
| Max Number of Processing (Preamp) Channels | 7.1 |
Sound Enhancements
| Discrete Power Amplifier | 7 |
| Audyssey | MultEQ XT |
| Audyssey Dynamic EQ / Dynamic Volume | Yes / Yes |
| Audyssey APP Support | Yes |
| Speaker Setup Presets | 2 |
| Compressed Audio Restorer | Yes |
Network
| HEOS Multiroom and Streaming | Yes |
| Lossy Formats: MP3 / WMA / AAC | Yes / Yes / Yes |
| Lossless Formats: FLAC / ALAC / WAV | Yes / Yes / Yes |
| DSD Audio Streaming | up to DSD5.6 |
| FLAC HD 192/24 | Yes |
| WAV 192/24 | Yes |
| ALAC 192/24 | Yes |
| Gapless playback | Yes (FLAC, WAV, ALAC, DSD) |
| AirPlay 2 | Yes |
| Roon Tested | Yes |
| Internet Radio | TuneIn |
| Spotify Connect* / Tidal* / Deezer* / others * | Yes / Yes / Yes / Yes |
| Amazon Prime Music* / Pandora* | Yes / Yes |
| Compatible with Remote APP for Smart Phones | Android / iOS |
| Compatible with Remote APP for Tablets | Android / iOS / Amazon Kindle |
| Ethernet Ports | Yes |
| Wi-Fi | Yes |
| Bluetooth | Yes |
| Bluetooth Headphone transmission | Yes |
HDMI
| HDMI Inputs: Back / Front | 6 (3x 8K) / 0 |
| HDCP2.3 support | Yes |
| HDMI Outputs: Main / Zone | 1 / No |
| HDMI max Resolution (8k / 4k) | 8k/60 - 4k/120 |
| HDMI to HDMI Scaling | up to 8K 60/50 |
| HDMI: 8K / 4K / CEC / eARC | Yes / Yes / Yes / Yes |
| HDMI: Dolby Vision / HDR 10+ / Dynamic HDR / HLG | Yes / Yes / Yes / Yes |
| HDMI: ALLM / QMS / QFT / VRR | Yes / Yes / Yes / Yes |
| HDMI pass-though in standby mode | Yes |
Multi-Room / CI
| HEOS Multiroom integrated | Yes |
| TV Sound grouping | Yes |
| Multiroom zones | 2 |
| Main room multichanel audio - Zone stereo downmix | Yes |
| Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog | Yes (2ch) / Yes (2ch) / Yes / Yes |
| Zone Audio Output: Speaker / Preout | Yes / Yes |
| Webbrowser Setup | Yes |
| IP Control / RS232 Control / Web Control / App Control | Yes / No / Yes / Yes |
| Remote In / Out | 1 / No |
Others
| Voice Control - Works with Amazon Alexa | Yes |
| Voice Control - Google Assist / Apple Siri | Yes / Yes |
| Auto Speaker Setup by Microphone | Audyssey MultEQ XT |
| FL Display | 1 line |
| Graphic User Interface - GUI | Hybrid GUI |
| GUI Languages | 3 |
| Setup Assistant | Yes |
| Quick Select Plus / Quick Select | Yes / No |
| Firmware Update by: Network / USB | Yes / Yes |
| Variable Cross Over | Yes |
| Optimized Bass Redirection | Yes |
| ECO Mode | Yes |
| Auto Power Off | Yes |
| Sleep Timer | Yes |
Inputs/Outputs
| Composite In / Out | 2 / 1 |
| Component In / Out | No / No |
| HDMI In / Out | 6 / 1 |
| Multi-room Video Out: Video / HDMI | No / No |
| Analogue In/out | 2 / No |
| Phono (MM) In | Yes |
| Digital In: Optical / Coaxial | 2 / 1 |
| Multi-room Out: Analog / Digital | Yes / No |
| Multichannel Pre-out | Yes (0.2) |
| Subwoofer Out | 2 |
| Speaker Terminal: Gold Plated Screw / Regular Screw | No / Yes |
| Number of Speaker Terminals | 7 |
| Speaker A / B | assignable |
| Bi-amp Drive | assignable |
| Multi-Room Speaker Terminal | assignable |
| Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB | No / No / No / No / Yes |
| USB Audio / Made for iPod / Made for iPhone | Yes / AirPlay / AirPlay |
| Tuner: FM / AM | Yes / Yes |
Specifications
| Number of Power Amps | 7 |
| Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive) | 80 W |
| Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) | 120 W |
| Power Output (6 ohm, 1 kHz, 10% 1ch Drive) | 175 W |
General
| Available colors: Black / Premium Silver | Yes / No |
| System Remote Control | RC-1244 |
| Pre-programmed / Learnable / LCD Display | No / No / No |
| Power Consumption in W | 430 |
| Power Consumption No-Sound (ECO On / Off) in W | 29 W / 39 W |
| Dimensions (W x D x H) | 434 x 339 x 151 mm |
| Standby Consumption in W | 0.1 |
| CEC Standby Consumption in W | 0.5 |
| Network Control On Consumption in W | 2.0 |
| Maximum Dimensions w/ Antenna (W x D x H) | 434 x 339 x 151 mm |
| Weight in kg | 8.6 |
| Carton Maximum Dimensions (W x D x H) in mm | 523 x 435 x 232 |
| Carton Weight (inc. product) in kg | 10.6 |
| Maximum Dimensions Antenna: Horizontal: (W x D x H) in Inches Antenna: Vertical: (W x D x H) in Inches W/O Antenna: (W x D x H) in Inches |
17.1× 13.3 × 6 ( 17.1 x 13.3 x 8.5) |
| Weight in LBS | 18.96 |
| Carton Maximum Dimensions (W x H x D) in Inches | 20.6 x 17.1 x 9.1 |
| Carton Weight (inc. product) in LBS | 23.37 |
