DENON AVR-X4800H

AVR-X4800H 9.4 Ch. 8K AV Receiver

Designed and manufactured in Japan, the powerful AVR-X4800H drives 9.4 channels of amplification. With Dolby Atmos and DTS:X, plus IMAX Enhanced and Auro 3D, the AVR-X4800H envelops larger living spaces in breathtaking 3D audio. With HEOS® Built-in, wireless stream your favourite music.

Powerful nine-channel amplifier

Discrete high-current amplifiers deliver up to 125W per channel (at 8 ohms, 20-20kHz, THD 0.05%) for more refined sound in large spaces.
3D audio experience

Get enveloped in sound with Dolby Atmos®, DTS:X®, IMAX Enhanced, and Auro 3D, along with Dolby Surround, DTS Neural:X, and Auro-Matic upmixer to optimize legacy content.
Configuration flexibility

AVR-X4800H offers many setup options and flexibility to adjust your home theater to meet your needs. Supports 11.4 channel processing capability, Pre-Amplifier mode, and optional Dirac Live upgradability (with a fee).
Advanced 8K home theater

8K video is supported on all seven HDMI inputs and two of the three outputs. With HLG, HDR, Dolby Vision, HDR10+ and Dynamic HDR pass-through, there's no need to worry about video compatibility or picture quality.
HEOS® Built-in technology

Stream music wirelessly from a variety of free and premium streaming services. Share content to HEOS-enabled devices, like Denon Home speakers, in other rooms.
Audyssey Room Correction Technology

Premium suite of Audyssey room correction features built-in for accurate setup and calibration to provide the most optimal listening experience for your room.
Built to high standards

Designed and manufactured in Denon's state-of-the-art manufacturing facility in Japan, where traditional practices fuse seamlessly with technologies designed for the future.
Over a century of innovation

Founded in 1910, Denon enhances the moments that matter through the relentless pursuit of quality, innovation, and audio performance.

TECHNICAL SPECIFICATIONS

Others

Auto Speaker Setup by Microphone	Audyssey MultEQ XT32 Dirac Live (upgrade)
Front Display	2-Line FLD
GUI Languages	English, Japanese, French

Inputs Outputs

HDMI In / Out	7 / 3
Analog In / Out	5 / 0
Phono (MM) In	Yes
Digital In : Optical / Coaxial	2 / 2
Multi-Room Out : Analog / Digital	2 / 0
Multichannel Pre-Out	Yes (11.4)
Subwoofer Out	4 (Independent)
Number of Speaker Terminals	11
Speaker A / B	Assignable
Bi-Amp Drive	Assignable
Multi-Room Speaker Terminal	Assignable

Specifications

Number of Power Amps	9
Power Output (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive)	125 W
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)	165 W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive)	235 W

General

System Remote Control	RC-1252
Pre-programmed / Learnable / LCD Display	Yes / No / No
Power Consumption in W	710 W
Power Consumption No-Sound (ECO On / Off) in W	65 W / 110 W
Standby Consumption in W	0.1 W
CEC Standby Consumption in W	0.5 W
Network Standby Consumption in W	Less than 2.0 W
Maximum Dimensions Antenna, Horizontal : (W x D x H) in mm Antenna, Vertical : (W x D x H) in mm W/O Antenna : (W x D x H) in mm	17.1 x 15.3 x 6.6 ( 17.1 x 15.3 x 9.3 ) 【 17.1 x 14.9 x 6.6 】
Weight in lbs	29.1 lbs
